Product
Impact Casement Windows
Rutao impact aluminum casement window is that the sash opening and closing is embedded in some horizontal directions. According to the opening method of the window, it can be divided into inner opening, outer opening, and inner reversing.
The inner opening type of window cleaning is convenient; the outer opening type is widely used in various decoration places because of the large opening area of the casement window, good ventilation, good sealing performance, sound insulation and excellent heat preservation performance.
For high-rise residents, in the face of typhoons, if window is not resistant to wind pressure, the impact is very large. In terms of airtight performance, the opening sector of the casement window is locked by a two-point lock or a heaven and earth lock.
Product Introduction
| Opening Style | Casement | Thermal Insulation | U≤ 0.5W/㎡K |
| Acoustic Performance | ≤ 35 DB | Air Tightness | ≤ 0.4m³(㎡h) |
| Wind Load Resistance | ≥ 3.5 KPa | Water Penetration | ≥ 1500Pa |
| Standard | FPA, NOA | Place of Origin | FoShan,GuangDong |
| Warranty | 10 Years | Application | Residential & Commercial |
| Performance | Hurricane Proof |
Customize Your Impact Casement Windows
Rutao is capable of customizing all kinds of aluminium impact casement windows, including american style hand-crank casement windows, push out casement windows. In the past 16 yrs, Rutao has designed and manufactured thousands of casement windows for customers, who come from USA, AU, CA and so on.
How to choose which style of casement windows for your own house or building projects ? Not only you can send us your design, drawings, or pictures, but also you could get our suggestions to ref. The opening styles of Casement windows are often designed to single panel, double panels, three or four panels. Moreover, it is usually combined with fixed windows according to your demands.
Product Details
Technical Specs
- Hi-Tech profile and reinforced material
- Reinforced glass fiber thermal insulation bar with high loading capacity
- Pressure extrusion for higher strength level
- Coex wire seal to protect against moisture
- Multi-point hardware lock system for weather sealing and burglarproofing
- Truss structure design for increased structural strength
- Tilt-turn system achieves the AAMA rating of CW-PG60
- Corner locking key ensures the smooth surface joint and improves corner stability
- Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue
Color & Coating Options
- Rutao Commen Color: Frosted Black, White Powder Coating
- Silver grey powder coating, Silver anodising with INTERPON powder
- Woodland grey(Satin), Ironstone(Stain), Shale Grey(Satin)
- Ultra Silver(Gloss), Dune(Sain), Paperbark(Satin), Primrose(Gloss)
- White Birch(Gloss), Surfmist(Matt), Architectural White(Satin)
- Pearl White(Gloss), Silver Pearl Kinetic(Satin), Black(Satin)
- Monument(Matt), Clear, Residential Bronze
- Cedar, Mahogany, Honey Gum, Snow Gum
- Select between factory-prefinished colors for fast delivery, or customized colors to better match your home
Glass Options
- Single Glass(5mm, 6mm, 8mm, 10mm….)
- Laminated Glass(5mm+0.76pvb+5mm)
- Double Toughened Glass(5mm+12air+5mm)
- Toughened Laminated Glass(5mm+12air+0.76pvb+5mm)
- Triple Toughened Glass(5mm+12air+5mm+12air+5mm)
- Thickness of single glass: 5-20mm
- Glass types: Frosted glass, Toughened glass, Low-e coated glass
- Special performance glass: Fireproof glass, Bulletproof glass
- Select from various types of glass, including but not limited to: tinted, low-e, sound-proof and burglarproof
Hardwares&Accessories Options
- Australia Doric hardware
- America CMECH hardware
- German Hoppe hardware
- China top SMOO Hardware
- German SIEGENIA hardware
- China top KINLONG hardware
- German ROTO hardware
- German GEZE hardware
- Rutao always choose seriously hardwares&accessories for customers with 10 years warranty
Common styles
Inspiration for Horizontal Windows
Horizontal slider windows offer not just a view but an experience, merging indoor comfort with the beauty of the outdoors. Get inspired in our gallery.
